5V RF Low Frequency TTL Level ID Card EM RFID Reader Board RFID 125khz Reader Module
Suoma is a cutting-edge enterprise with an in-house R&D team. Our core technical and sales staff are seasoned professionals with over a decade of experience in the RFID industry.
At Suoma, we specialize in RFID embedded modules. Through extensive research and development, we have developed a diverse range of RFID modules that cater to various products and projects. Whether you require the most advanced solution, the highest quality, or the most cost-effective option, we offer a variety of levels and choices to meet your specific needs.
Our standard module offerings include the 125kHz low frequency series, the 13.56MHz high frequency series, and the 860-960MHz UHF series.
Instruction:
IS610 is a 125KHz read-only module for EM4100/TK4100 125KHz cards, which can read and output CSN card number.
It has option of Wiegand26, RS232 and TTL output format.
Features:
125KHz Operating Frequency
Available to be embedded into individual items
Read CSN card number only
Different output formats
Module NO.:
| Module NO. | Interface |
| IS610-W | WG26 |
| IS610-T | TTL |
| IS610-S | RS232 |
Parameter:
| IS610 |
| Frequency | 125KHz |
| Supporting Card | EM4100/TK4200/EM4200 Card |
| Interface | Wiegand26, TTL, RS232 |
| Power Supply | 5V & 3.3V |
| Card Reading Distance | >8cm(Depending on label size and surroundings) |
| Operating Temperature | -10℃~ 70℃ |
| Antenna | External , Variety of optional specifications |
| Dimension | 39mm *19mm * 9mm |
PIN Definition:
| PIN | PIN NO. | Wiegand26 | RS232/TTL |
| P1 | 1 | NC | NC |
| | 2 | DATA 0 | RXD |
| | 3 | DATA 1 | TXD |
| | 4 | GND | GND |
| | 5 | +5VDC | +5VDC |
| P2 | 1 | ANTENNA-1 | ANT-1 |
| | 2 | ANTENNA-2 | ANT-2 |
| P3 | 1 | LED- | LED- |
| | 2 | LED+ | LED+ |
| | 3 | NC | NC |
PIN Definition Diagram:
Popular antenna size options:(customizable)
Application:
Table PC
Lift control
POS terminal
Parking system
Access control
Handheld terminal
Attendance application
Recreational Machine
Barrier gate/rapid-open gate
FAQ
Q1. Can I have a sample order for rfid reader/module?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 1-3 days for Sample preparing ,5-10 working days for mass production.
Q3. Do you have any MOQ limit for rfid reader/module order?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. There are some cheaper opitions for certain area which takes more time like 8-20 days, like Express Southeast Asia,Middle East Express,ARAMEX,South America Express.
Q5. How can I pay for an order?
A: We can accept TT(telegraphic transfer), western union, paypal, alipay, wechat and online order.
Q6. How to proceed an order for RFID reader/module?
A: Firstly let us know your requirements or application,for us to confirm the detailed module No.of the product you need.
Secondly we quote the best offer of products and shipping cost according to your requested qty.
Thirdly we make the proforma invoice for you to transfer the payment.
Fourthly we arrange the production and shipment after payment is received by our account.
